Form Factor: ATX12V v3.1 (supports latest Intel ATX 3.1 and PCIe 5.1 standards)
Efficiency: 80 Plus Gold certified (≥ 90% efficiency at typical load) and Cybenetics Gold rating
Modular Design: Full modular cables for cleaner installs and better airflow
Topology: Active PFC + Full Bridge SRC LLC + DC-to-DC
24-pin ATX: 1 x main power
CPU EPS: Typically 1–2 x 4+4 pin (varies by wattage model)
PCIe: 1 x PCIe 6+2 pin
1 x 12V-2x6 (16-pin) for PCIe 5.x GPUs
SATA: ~4 x SATA
Peripheral (Molex): ~1 x 4-pin
Efficiency: ≥ 90% typical (50% load)
Hold-Up Time: ≥ 16 ms at 80% load
Power Good Signal: ~100–150 ms
Dimensions (W × L × H): ~150 × 140 × 86 mm (standard ATX PSU size)
