GPU Engine Specs

CUDA Cores: 10752

Boost Clock (MHz): 2617MHz

Base Clock (MHz): 2295MHz



Thermal and Power Spec

Minimum System Power Requirement (W): 850W

Supplementary Power Connectors: 3x PCIe 8-pin cables (adapter in box) OR 1x 450 W or greater PCIe Gen 5 cable



Memory Specs

Memory Clock: 30Gbps

Standard Memory Config: 16GB

Memory Interface: GDDR7

Memory Interface Width: 256-bit

Memory Bandwidth (GB/sec): 960 GB/sec



Feature Support

Real-Time Ray Tracing: Yes

Ray Tracing Cores: 4th Generation, 171 TFLOPS

Tensor Cores: 5th Generation, 1801 AI TOPS

NVIDIA Architecture: Blackwell

Microsoft DirectX: 12 Ultimate

NVIDIA DLSS: 4

NVIDIA Ansel: Yes

NVIDIA FreeStyle: Yes

Bus Support: PCI Express Gen 5

NVIDIA ShadowPlay: Yes

OS Certification: Windows 11, Linux, FreeBSDx86

NVIDIA Highlights: Yes

NVIDIA G-SYNC™-Ready: Yes

Game Ready Drivers: Yes

NVIDIA Studio Drivers: Yes

NVIDIA GPU Boost™: Yes

Vulkan API: 1.4

OpenGL: 4.6

NVIDIA Encoder: 2x Ninth Generation

NVIDIA Decoder: 2x Sixth Generation



Accessories

Graphics Card Dimensions

Length: 300mm

Height: 116mm

Width: 41mm



Display Support

Multi Monitor: up to 4

Maximum Digital Resolution: 4K at 480Hz or 8K at 165Hz with DSC

HDCP: 2.3

Standard Display Connectors: 3x DisplayPort 2.1b, 1x HDMI 2.1b
