Chipset: INTEL B860

CPU: Supports Intel® Core™ Ultra Processors (Series 2) LGA 1851

Memory:

2x DDR5 UDIMM, Maximum Memory Capacity 128GB

Memory Support DDR5 9066 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s

Max. overclocking frequency:

• 1DPC 1R Max speed up to 9066+ MT/s

• 1DPC 2R Max speed up to 7200+ MT/s

Supports Intel® POR Speed and JEDEC Speed

Supports Memory Overclocking and Intel® XMP 3.0

Supports Dual-Controller Dual-Channel mode

Supports Non-ECC, Un-buffered memory

Supports CUDIMM

Onboard Graphics:

1x HDMI™

Support HDMI™ 2.1, maximum resolution of 4K 60Hz*

1x DisplayPort

Support DisplayPort 1.4, maximum resolution of 4K 60Hz*

1x Type-C DisplayPort

Supports DisplayPort 1.4 over USB Type-C®, maximum resolution of 4K 60Hz*

1x DVI

Support DVI-D, maximum resolution of 1920x1200 60Hz*

1x VGA

Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz*

Slot:

1x PCI-E x16 slot

2x PCI-E x1 slot

1x PCI slot

PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)

PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset)

PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset)

Storage:

2x M.2

M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices

M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices

4x SATA 6G

OPERATING SYSTEM: Support for Windows® 11 64-bit

PCB Info: mATX 243.84mmx220mm
