Processor (CPU)

• Model: Realtek RTD1619B
• Architecture: 64-bit
• Cores / Threads: 4-core
• Clock Speed: 1.7 GHz
• Hardware Encryption Engine: Supported


Memory

• Installed Memory: 1 GB DDR4 (non-ECC)

Note:
Synology may use memory modules with the same or higher frequency depending on supply, while maintaining identical performance and compatibility.

Storage

• Drive Bays: 1
• Supported Drives:
  • 3.5" SATA HDD
  • 2.5" SATA SSD (requires optional disk holder)
• Hot-Swappable: No

Note:
“Compatible drive type” refers to tested drives, not maximum speed.

Ports & Connectivity

• LAN Port: 1 × RJ-45 (1GbE)
• USB Ports: 2 × USB 3.2 Gen 1

Notes:

• • LAN MTU max: 1,500 bytes
    USB 3.0 renamed to USB 3.2 Gen 1 (USB-IF, 2019)

Design & Build

• Dimensions (H × W × D): 166 × 71 × 224 mm
• Weight: 0.7 kg

Cooling & Noise

• Fan: 1 × 60 mm
• Fan Modes:
  • Full-Speed
  • Cool
  • Quiet
  • Low-power
• Noise Level: 19.0 dB(A)

Power

• Power Adapter: 36 W
• Input Voltage: 100V–240V AC
• Frequency: 50/60 Hz

Power Consumption

• Active: 10.69 W
• HDD Hibernation: 3.44 W

Thermal Output

• Active: 36.50 BTU/hr
• HDD Hibernation: 11.75 BTU/hr

Features

• Adjustable Front LED Brightness
• Power Recovery
• Scheduled Power On/Off
• Wake on LAN / WAN

Operating Conditions

• Operating Temp: 0°C to 40°C
• Storage Temp: -20°C to 60°C
• Humidity: 5% to 95% RH

Certifications

• FCC • CE • BSMI • VCCI • RCM • UKCA • EAC • CCC • KC

Environmental Compliance

• RoHS Compliant

Package Contents

• Main Unit ×1
• Accessory Pack ×1
• AC Power Adapter ×1
• RJ-45 LAN Cable ×1
• Quick Installation Guide ×1
