TP-Link TL-SG105PE 5-Port Gigabit Easy Smart Switch with 4-Port PoE+ Desktop Network Ethernet Switch Hub for Internet
- Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3at
- Interface: Five 10/100/1000Mbps RJ45 Ports, AUTO Negotiation/AUTO MDI/MDIX
- Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m), 100BASE-TX: UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m), 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m)
- Fan Quantity: Fanless
- Power Supply: External Power Adapter (Output: 53.5 VDC/1.31 A)
- PoE Ports (RJ45): Standard: 802.3 af/at compliant, PoE Ports: Port 1- Port 4, PoE Power Budget: 65 W
- Dimensions (W x D x H): 3.9 × 3.9 × 1.0 in (99.8 × 98 × 25 mm)
- Max. Power Consumption: 4.52 W (220V/50Hz with no PD connected), 75.16 W (220V/50Hz with 65 W PD connected)
-
Max. Heat Dissipation: 15.41 BTU/h (with no PD connected), 256.30 BTU/h (with 65 W PD connected)
Product Information
Product Information
Shipping & Returns
Shipping & Returns
TP-Link TL-SG105PE 5-Port Gigabit Easy Smart Switch with 4-Port PoE+ Desktop Network Ethernet Switch Hub for Internet
TP-Link TL-SG105PE 5-Port Gigabit Easy Smart Switch with 4-Port PoE+ Desktop Network Ethernet Switch Hub for Internet
- Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3at
- Interface: Five 10/100/1000Mbps RJ45 Ports, AUTO Negotiation/AUTO MDI/MDIX
- Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m), 100BASE-TX: UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m), 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m)
- Fan Quantity: Fanless
- Power Supply: External Power Adapter (Output: 53.5 VDC/1.31 A)
- PoE Ports (RJ45): Standard: 802.3 af/at compliant, PoE Ports: Port 1- Port 4, PoE Power Budget: 65 W
- Dimensions (W x D x H): 3.9 × 3.9 × 1.0 in (99.8 × 98 × 25 mm)
- Max. Power Consumption: 4.52 W (220V/50Hz with no PD connected), 75.16 W (220V/50Hz with 65 W PD connected)
-
Max. Heat Dissipation: 15.41 BTU/h (with no PD connected), 256.30 BTU/h (with 65 W PD connected)
$38.75
TP-Link TL-SG105PE 5-Port Gigabit Easy Smart Switch with 4-Port PoE+ Desktop Network Ethernet Switch Hub for Internet—
$38.75
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
- Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3at
- Interface: Five 10/100/1000Mbps RJ45 Ports, AUTO Negotiation/AUTO MDI/MDIX
- Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m), 100BASE-TX: UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m), 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m)
- Fan Quantity: Fanless
- Power Supply: External Power Adapter (Output: 53.5 VDC/1.31 A)
- PoE Ports (RJ45): Standard: 802.3 af/at compliant, PoE Ports: Port 1- Port 4, PoE Power Budget: 65 W
- Dimensions (W x D x H): 3.9 × 3.9 × 1.0 in (99.8 × 98 × 25 mm)
- Max. Power Consumption: 4.52 W (220V/50Hz with no PD connected), 75.16 W (220V/50Hz with 65 W PD connected)
-
Max. Heat Dissipation: 15.41 BTU/h (with no PD connected), 256.30 BTU/h (with 65 W PD connected)
